12.8V 150Ah Electric Vehicle Lithium Battery High Density LiFePo4 Lithium Battery

1000pcs
MOQ
Inquiry
Price
12.8V 150Ah Electric Vehicle Lithium Battery High Density LiFePo4 Lithium Battery
Features Gallery Product Description Request A Quote
Features
Specifications
Nominal Voltage: 12.8V
Rated Capacity: 150Ah
Energy: 1920Wh
Resistance: ≤65mΩ
Efficiency: 0.99
Cycle Life: >4000cycles @1C,80%DOD
Self Discharge: 2% Per Month
Max.Modulesin Series/Parallel: 3P/4S
Highlight:

12.8V Electric Vehicle Lithium Battery

,

150Ah Electric Vehicle Lithium Battery

,

High Density LiFePo4 Lithium Battery
Basic Infomation
Place of Origin: China
Brand Name: Ecolite
Certification: UN38.3 MSDS CE
Model Number: 12.8V 150Ah
Payment & Shipping Terms
Payment Terms: L/C, T/T
Product Description

High Density LiFePo4 Lithium Battery 12.8v 150Ah For Golf Carts





12.8V 150Ah Electric Vehicle Lithium Battery High Density LiFePo4 Lithium Battery 0



Electrical Parameters Mechanical Parameters
Nominal Voltage 12.8V Dimension(LxWxH) 345x190x245mm
Rated Capacity 150Ah 13.58x7.48x9.65
Energy 1920Wh Weight 15kg
Resistance ≤65mΩ Terminal Type M8
Efficiency 0.99 Battery Housing ABS
Cycle Life >4000cycles @1C,80%DOD Housing Protection IP67
Self Discharge 2% per Month CellType-Chemistry LiFe PO4 Cell
Max.Modulesin Series/Parallel 3P/4S soc Display(optional) /



Discharge Parameters Charge Parameters
Continuous Discharge Current 100A Charge Method CC-CV
Maximum Discharge Current 200A(＜3S) Charge Voltage 14.4~14.8V
Recommended Volt. Disconnect 10V Recommended Float Voltage 13.8V
BMS Discharge Cut.offVoitage 8.8V Recommended Charge Current 20A
Reconnect Voltage 10.4V Maximum Charge Current 100A
Short Circuit Protection 300-800us BMS Charge Cut-off Voltage 15V



Temperature Parameters
Discharge Temperature -20℃to 60℃
Charge Temperature 0℃to 60℃
Storage Temperature -40℃to 70℃
BMS High Temperature Cut-off 78℃



Q :Do you provide free sample ?
A: Yes, a few pcs free sample can be provided, but freight will be charged

Q: what is the warranty?
A: one year

Q:What is your payment term ?
A: T/T,L/C

Q:do you accepte OEM order ?
A: Yes,you can print yourself logo, also we can provide the design of outlook for your special battery pack

Q :How many cells you can produce per month?
A: 1.8million

Q :What is the mode of transport?
A: usually by sea

Q:Which certificates do you have
A:We have un38.3,MSDS…etc.
