UN38.3 MSDS Marine LiFePO4 Battery 12.8V 600Ah For Harsh Marine Environments

5000
MOQ
Inquiry
Price
UN38.3 MSDS Marine LiFePO4 Battery 12.8V 600Ah For Harsh Marine Environments
Features Gallery Product Description Request A Quote
Features
Specifications
Nominal Voltage: 12.8V
Rated Capacity: 600Ah
Energy: 7680Wh
Resistance: ≤50mΩ
Efficiency: ≥0.98
Cycle Life: >4000cycles @0.5C,80% DOD
Self Discharge: <5% Per Month
Cell Series/Parallel: 4S/2P
Discharge: -20℃ To 60℃
Charge Temperature: 0℃to 55℃
Storage Temperature: -20℃ To 60℃
BMS High Temperature Cut-off: 65℃
Highlight:

Marine LiFePO4 Battery 12.8V

,

Marine LiFePO4 Battery 600Ah
Basic Infomation
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Certification: UN38.3 MSDS
Model Number: Boat Marine
Payment & Shipping Terms
Packaging Details: Carton Pallet Container
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 500000
Product Description

12.8V 600Ah Marine LiFePO4 Battery for Harsh Marine Environments



Mechanical Parameters
Dimension(LxWxH) 668x241x338mm
Dimension(LxWxH) 26.30x 9.49x 13.31
Weight 52Kg
Terminal Type M8
Battery Housing SPCC
Housing Protection IP65
Cell Type-Chemistry LiFePO4 Cell
Communication

CAN/Bluetooth





Discharge Parameters
Continuous Discharge Current 300A
Pulse Discharge Current 500A (<10S)
Recommended Volt. Disconnect 10V
BMS Discharge Cut-off Voltage 10V
Reconnect Voltage 10.8V
Short Circuit Protection 300-800us



Charge Parameters
Charge Method CC-CV
Charge Voltage 14.2~14.6V
Recommended Float Voltage 13.3~13.4V@100%
Recommended Charge Current    /
Maximum Charge Current 300A
BMS Charge Cut-off Voltage 14.8V
