Marine Lithium Iron Phosphate Battery Lifepo4 560Ah 12V Lifepo4 Battery Integrate BMS

5000
MOQ
Inquiry
Price
Marine Lithium Iron Phosphate Battery Lifepo4 560Ah 12V Lifepo4 Battery Integrate BMS
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Voltage: 12.8V
Rated Capacity: 560Ah
Nominal Energy: 7168Wh
Resistance: ≤30mΩ
Cycle Life: >6000cycles @0.5C,80% DOD
Self Discharge: <5% Per Month
Max, Modules In Series,Parallel: 4S/2P
Dimension(LxWxH): 401x351x342mm
Battery Housing: ABS
Cell Type-Chemistry: LiFePO4 Cell
Highlight:

Marine Lithium Iron Phosphate Battery

,

560Ah Marine Lithium Iron Phosphate Battery

,

12V Marine Lithium Iron Phosphate Battery

Basic Infomation
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Payment & Shipping Terms
Packaging Details: Carton Pallet Container
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 5000 Units per month
Product Description

Ecolite Marine Lithium Iron Phosphate Battery Lifepo4 560Ah 12V Lifepo4 battery integrate BMS

FEATURES

Lithium lron Phosphate (LiFePO4).

The SafestLithium Technology.

Integrated Battery Management System(BMS)

Maximum support 4 in series or 4 in parallel.

PERFORMANCE

Long Cycle Life >4000cycles@ 80%DOD.

High Density,High Discharge Current,High Tempera-ture Range.

Low Weight,Free Maintenance.

Fast Charging.

Environment Friendly.

Marine Lithium Iron Phosphate Battery Lifepo4 560Ah 12V Lifepo4 Battery Integrate BMS 0

Electrical Parameters
Nominal Voltage 12.8V
Rated Capacity 560Ah
Energy 7168Wh
Resistance ≤30mΩ
Efficiency ≥0.98
Cycle Life >6000cycles @0.5C,80% DOD
Self Discharge <5% per Month
Max, Modules in Series,Parallel 4S/2P



MechanicalParameters
Dimension(LxWxH) 401x351x342mm
Dimension((LxWxH) 15.79x 13.82x 13.46
Weight 50Kg
Terminal Type M8
Battery Housing ABS
Housing Protection IP65
Cell Type-Chemistry LiFePO4 Cell
Communication Bluetooth



Discharge Parameters
Continuous Discharge Current 200A
Pulse Discharge Current 300A(<1S)
Recommended Volt. Disconnect 10V
BMS Discharge Cut-off Voltage 10V
Reconnect Voltage 10.8V
Short Circuit Protection 300-800us



Charge Parameters
Charge Method CC-CV
Charge Voltage 14.2~14.6V
Recommended Float Voltage 13.3~13.4V@100%
Recommended Charge Current /
Maximum Charge Current 200A
BMS Charge Cut-off Voltage 14.8V



Temperature Parameters
Discharge Temperature -20℃ to 60℃
Charge Temperature 0℃ to 55℃
Storage Temperature -20℃ to 60℃
BMS High Temperature Cut-off 65℃

Marine Lithium Iron Phosphate Battery Lifepo4 560Ah 12V Lifepo4 Battery Integrate BMS 1
 Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
