51.2V 100A Lithium Iron Phosphate Energy Storage System Container Battery

Name: 51.2V 100A Lithium Iron Phosphate Energy Storage System Container Battery
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: 48100
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Certification: UN38.3 MSDS CE RoHS

Model Number: 48100

Payment & Shipping Terms

Minimum Order Quantity: 500

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: L/C, T/T

Supply Ability: 4000 Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          51.2V Lithium Iron Phosphate Battery, 100A Lithium Iron Phosphate Battery, 48100 Deep Cycle LiFePO4 Battery


Nominal Voltage:	51.2V	Rated Capacity:	100Ah
Rated Energy:	5120Wh	Resistance:	≤30mΩ
Efficiency:	≥0.98	Cycle Life:	>4000cycles @1C,80% DOD
Self Discharge:	<5% Per Month	Max.Modules In Series/Parallel:	16S/1P
Dimension(WxDxH):	482.6x592x133mm	Weight:	45.5kg
Terminal Type:	FCC06B0	Battery Housing:	Cold Rolled Steel Sheet
Housing Protection:	IP30	Continuous Discharge Current:	100A
Communication:	RS485/RS232

Nominal Voltage:	51.2V
Rated Capacity:	100Ah
Rated Energy:	5120Wh
Resistance:	≤30mΩ
Efficiency:	≥0.98
Cycle Life:	>4000cycles @1C,80% DOD
Self Discharge:	<5% Per Month
Max.Modules In Series/Parallel:	16S/1P
Dimension(WxDxH):	482.6x592x133mm
Weight:	45.5kg
Terminal Type:	FCC06B0
Battery Housing:	Cold Rolled Steel Sheet
Housing Protection:	IP30
Continuous Discharge Current:	100A
Communication:	RS485/RS232

Description

51.2V 100A Lithium Iron Phosphate Energy Storage System Container Battery

48100(51.2V100A) Lithium lron Phosphate (LiFePO4) Integrated BMS deep cycle battery for house solar

Specifications

Electrical Parameters
Nominal Voltage	51.2V
Rated Capacity	100Ah
Energy	5120Wh
Resistance	≤30mΩ
Efficiency	≥0.98
Cycle Life	>4000cycles @1C,80% DOD
Self Discharge	<5% per Month
Max.Modules in Series/Parallel	16S/1P

Mechanical Parameters
Dimension(WxDxH)	482.6x592x133mm
Dimension(WxDxH)	19x23.30x5.24
Weight	45.5kg
Trminal Type	FCC06B0
Battery Housing	Cold rolled steel sheet
Housing Protection	IP30
Cell Type-Chemistry	LiFePO4 Cell
Communication	RS485/RS232

Discharge Parameters
Continuous Discharge Current	100A
Pulse Discharge Current	150A (<0.5S)
Recommended Volt. Disconnect	40V
BMS Discharge Cut-off Voltage	40V
Reconnect Voltage	43.2V
Short Circuit Protection	300-800us

Charge Parameters
Charge Method	CC-CV
Charge Voltage	56.8-58.4V
Recommended Float Voltage	54~55.2V
Recommended Charge Current	50A
Maximum Charge Current	100A
BMS Charge Cut-off Voltage	59V

Temperature Parameters
Discharge Temperature	-20℃ to 60℃
Charge Temperature	0℃ to 55℃
Storage Temperature	-20℃ to 60℃
BMS High Temperature Cut-off	65℃
