LiFePO4 Battery Energy Storage System 20Ah 48V Lithium Iron Phosphate Battery With BMS

5000
MOQ
Inquiry
Price
LiFePO4 Battery Energy Storage System 20Ah 48V Lithium Iron Phosphate Battery With BMS
Features Gallery Product Description Request A Quote
Features
Specifications
Nominal Voltage: 48V
Rated Capacity: 20Ah
Energy: 960Wh
Resistance: ≤30mΩ
Effciency: ≥0.98
Cycle Life: >2000cycles @1C,80% DOD
Self Discharge: <5% Per Month
Max.Modules In Series,Parallel: 15S/3P
Highlight:

Battery Energy Storage System 20Ah

,

LiFePO4 Battery Energy Storage System

,

20Ah 48V Lithium Iron Phosphate Battery
Basic Infomation
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Payment & Shipping Terms
Packaging Details: Carton Pallet Container
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 5000 Units per month
Product Description

LFP4820(48V20Ah) Lithium lron Phosphate(LiFePO4)Integrated Battery Management System(BMS)

Specifications

Electrical Parameters
Nominal Voltage 48V
Rated Capacity 20Ah
Energy 960Wh
Resistance ≤30mΩ
Effciency ≥0.98
Cycle Life >2000cycles @1C,80% DOD
Self Discharge <5% per Month
Max.Modules in Series,Parallel 15S/3P



MechanicalParameters
Dimension(WxDxH) 442x245x88mm
Dimension(WxDxH) 17.4 x 9.64x3.464"
Weight 13kg
Terminal Type M4
Battery Housing SPCC
Housing Protection IP30
Cell Type-Chemistry LiFePO4 Cell
Communication RS485/RS232



Discharge Parameters
Continuous Discharge Current 20A
Pulse Discharge Current 25A(<10S)
Recommended Volt. Disconnect 37.5V
BMS Discharge Cut-off Voltage 37.5V
Reconnect Voltage 40.5V
Short Circuit Protection 300-800us



Charge Parameters
Charge Method CC-CV
Charge Voltage 53.25~54.75V
Recommended Float Voltage 50.6~51.75V
Recommended Charge Current 10A
Maximum Charge Current 20A
BMS Charge Cut-off Voltage 54.75V



Temperature Parameters
Discharge Temperature -20℃ to 60℃
Charge Temperature 0℃ to 55℃
Storage Temperature -20℃ to 60℃
BMS High Temperature Cut-off 60℃
Tag:

High Voltage Energy Storage

LTO Lithium Titanate Battery

Solar Energy Storage System
