Lithium Battery Charger 12V 50Ah With Repair Charging Function And Wide Voltage Input

5000

MOQ

Inquiry

Price

Lithium Battery Charger 12V 50Ah With Repair Charging Function And Wide Voltage Input

Features Gallery Product Description Request A Quote

Features

Specifications

Input Voltage: 100VAC-240VAC 50/60HZ

Output Voltage: 6VDC/12VDC

Output Current: 1.8A±10%/5A±10%

Charging Voltage Range: 12V Charging Mode:2.5V-15V ,6V Charging Mode:2.5V-7.5V

Full Voltage: 12V Charging Mode:14.2V-15V,6V Charging Mode:7.1V-7.5V

Size: 195×77×46mm

Weight: 0.5kg

Highlight:

12V 50Ah Lithium Battery Charger

,

Wide Voltage Input Lithium Battery Charger

,

Repair Charging Function Lithium Battery Charger

Basic Infomation

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Payment & Shipping Terms

Packaging Details: Carton Pallet Container

Payment Terms: L/C, T/T

Supply Ability: 500000

Gallery

Lithium Battery Charger 12V 50Ah With Repair Charging Function And Wide Voltage Input

Product Description

Lithium Battery Charger 12V 50Ah

FEATURES

Supports charging lead-acid, AGM and 4-seres lithium iron phosphate batteries.
Supports charging two types of AGM batteries, 6/12V It has overcurrent, overvoltage, reverse connection. over temperature,and short circuit protection Equipped with repair charging function. Equipped with 12V power supply function. IP65 protection level.
Wide voltage input
Simple operation

Lithium Battery Charger 12V 50Ah With Repair Charging Function And Wide Voltage Input 0

Specifications

Project	Specifications/Scope
Input Voltage	100VAC-240VAC 50/60HZ
Output Voltage	6VDC/12VDC

Input
Output Current	1.8A±10%/5A±10%
Charging Voltage Range	12V charging mode: 2.5V-15V, 6V charging mode: 2.5V-7.5V
Full Voltage	12V charging mode:14.2V-15V, 6V charging mode: 7.1V-7.5V
Maintenance Voltage	6V (6.75V±0.15V); 12V (13.5V±0.2V)
Timing	Battery voltage below 14.2V±0.2V (12V charging) or 7.1V±0.2V(6V charging) timed for 72 hours Battery voltage above 14.2V±0.2V (12V charging) for 36 hours After charging for 2 hours, the charging voltage still cannot reach 12V±0.2V(12V charing ) or 6V±0.2V(6V charging). Set a timer for 2 hours
Reverse Polarity Protection	Reverse connection display light flashing
Overvoltage Protection	External voltage too high, overvoltage indicator light on
Over Temperature Protection	The charger is overheating ,and the overheating indicator light
Battery Damage Detection	The battery damage indicator light is flashing
Short Circuit Protection	Automatic recovery ,charger has no output
Operation Temperature	-10%-45%
Size	195×77×46mm
Weight	0.5kg
