Ecolite NCM Battery Cellpower Cyclic Battery 25.2V 41.6Ah Lithium Battery With BMS

Name: Ecolite NCM Battery Cellpower Cyclic Battery 25.2V 41.6Ah Lithium Battery With BMS
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: ECONMC24-40
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite

Certification: UN38.3 MSDS CE

Model Number: ECONMC24-40

Payment & Shipping Terms

Minimum Order Quantity: 2000pcs

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 5-8 work days

Payment Terms: L/C, T/T

Supply Ability: 5000 units/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              25.2V 41.6Ah Lithium Battery, NCM Cellpower Cyclic Battery, Ecolite Battery Cellpower Cyclic Battery


Nominal Voltage:	25.2V	Rated Capacity:	41.6Ah
Energy:	1048.32Wh	Resistance:	≤65mΩ
Efficiency:	0.99	Cycle Life:	＞1000cycles @0.5D，1C 70% DOD
Self Discharge:	2% Per Month	Max.Modules In Series/Parallel:	16P/7S

Nominal Voltage:	25.2V
Rated Capacity:	41.6Ah
Energy:	1048.32Wh
Resistance:	≤65mΩ
Efficiency:	0.99
Cycle Life:	＞1000cycles @0.5D，1C 70% DOD
Self Discharge:	2% Per Month
Max.Modules In Series/Parallel:	16P/7S

Description

Ecolite NCM Battery Cellpower Cyclic Battery 25.2V 41.6Ah Lithium Battery With BMS

Ecolite NCM Battery Cellpower Cyclic Battery 25.2V 41.6Ah Lithium Battery With BMS

Features

Li-NMC:The Safest Lithium Technology. Integrated Battery.

Management System(BMS).

Performance

Long Cycle Life ＞1000cycles@70%DOD.

High Density,High Discharge Current,High Temperature Range.
Low Weight,Free Maintenance.
Fast Charging.

Environment Friendly.

Electrical Parameters		Mechanical Parameters
Nominal Voltage	25.2V	Dimension(LxWxH)	198x166x170mm
Rated Capacity	41.6Ah	Dimension(LxWxH)	7.80x 6.54x 6.69"
Energy	1048.32Wh	Weight	7.5kg
Resistance	≤65mΩ	Terminal Type	M6
Efficiency	0.99	Battery Housing	ABS
Cycle Life	>1000cycles @0.5D,1C 70% DOD	Housing Protection	IP65
Self Discharge	2% per Month	Cell Type-Chemistry	NMC
Max, Modules in Series/Parallel	16P/7S	SoC Display(Optional)	/

Discharge Parameters		Charge Parameters
Continuous Discharge Current	20A	Charge Method	CC-CV
Pulse Discharge Current	60A (<3S)	Charge Voltage	28.7-29.4V
Recommended Volt. Disconnect	19.25V	Recommended Float Voltage	28V
BMS Discharge Cut-off Voltage	18.9V	Recommended Charge Current	20A
Reconnect Voltage	20.3V	Maximum Charge Current	20A
Short Circuit Protection	300-800us	BMS Charge Cut-off Voltage	30V

Temperature Parameters
Discharge Temperature		-20℃to 60℃
Charge Temperature		0℃ to 50℃
Storage Temperature		-10℃to 35℃
BMS High Temperature Cut-off		65℃

Q :Do you provide free sample ?
A: Yes, a few pcs free sample can be provided, but freight will be charged

Q: what is the warranty?
A: one year

Q:What is your payment term ?
A: T/T,L/C

Q:do you accepte OEM order ?
A: Yes,you can print yourself logo, also we can provide the design of outlook for your special battery pack

Q :How many modules you can produce per month?
A: 5000 pcs

Q :What is the mode of transport?
A: usually by sea

Q:Which certificates do you have
A:We have un38.3,MSDS…etc.
