Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication

50
MOQ
Inquiry
Price
Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication
Features Gallery Product Description Request A Quote
Features
Specifications
Voltage: 24V
Capacity: 100A
Weight: 40kg
Dimension(LxWxH): 600x400x650mm
Input Voltage Range: AC304V~AC456V
Input Limit Voltage: AC490V
Maximum Output Current: 100A(Typical)
Steady Current Accuracy: 0.8
Output Current Error: ±1%
Highlight:

100A Lifepo4 Charger

,

Lithium Ion Battery Charger

,

Forklift Lithium Ion Battery Charger

Basic Infomation
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Payment & Shipping Terms
Packaging Details: Carton Pallet Container
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 500000
Product Description

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger with CAN communication

FEATURES

This series of chargers has high conversion efficiency,high voltage regulation/current regulation accuracy,and small output current ripple. Due to the use of high-frequency technology switches, the charging machine is characterized by power saving, easy control,wide range adjustment, small size and light weight.Reliable quality. Long service cycle.



Protection function

 overvoltage, overcurrent, overpower, overheating, undervoltage,short ciruit,reverse connection.





Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 0

Basic Parameters
Voltage 24V
Capacity 100A
Weight 40kg
Dimension(LxWxH) 600x400x650mm



Input
Input Voltage Range AC304V~AC456V
Input Limit Voltage AC490V
Input Frequency Range 50/60Hz
Power Factor 0.99
THD 3.50%
Input Inrush Current 10A(maximum)
Input Type Three-phase three-wire +PE



Output
Output Voltage Range DC18V~DC29.2V
Output Voltage Error ±0.5%
Steady Voltage Accuracy ±0.5%
Output Voltage Ripple Factor ±1%
Maximum Output Current 100A(Typical)
Output Current Adjustment Range 1-100A
Output Current Error ±1%
Steady Current Accuracy 0.8
Communicate CAN



Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 1

Output connector

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 2Output connector use 160A,150V Rema,Anderson or custom connectors.





Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 3

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 4

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 5







Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 6



Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 7

Hefei ECOLTO Energy is a China leading manufacturer of highquality lithium batteries, From cells to automated modules to PACK production lines, we provide you with high-quality products. Wehave our own intellectual property and full-automatic equipment, to meet different customization needs, and provide you with a onestop service.

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 8



We have our own production workshop. We develop and produce everything from battery cells to Pack assembly. We have been in this industry for more than ten years. We serve every customer with a reliable, trustworthy and pragmatic attitude.

Forklift 24V 48V 100A Lifepo4 Charger Lithium Ion Battery Charger With CAN Communication 9

Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
