LFP 29.2V 25A RV Lithium Battery Intelligent Fan Control IP20 Protection

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Payment & Shipping Terms

Minimum Order Quantity: 5000

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: L/C, T/T

Supply Ability: 5000 Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      LFP RV Lithium Battery, IP20 RV Lithium Battery


Basic Parameters:	LFP 29.2V25A	Weight:	2.05Kg
Dimension(LxWxH):	283x142x64mm	Continuous Out-put Power:	730W
IP Protection:	IP20	In-put Voltage:	AC220V~240V
In- Put Frequency:	47~63Hz	Out-put Voltage:	DC20V-DC29.2V
Out-put Current:	25A(±6%)	Working Temperature:	-10°C~+45°C
Saving Temperature:	20°℃~+60°C	Relative Temperature:	20-90%
Atmospheric Pressure:	70~106Kpa(No Condensation)	Cooling Way:	Intelligent Fan Control
Altitude:	≤3000m	Stable Current Charging Period:	24-27.6VDC
Stable Voltage Charging Period:	29.2VDC	Automatic Off Chargin:	Charging Voltage= 29.2V And Charging Current< 1A

Basic Parameters:	LFP 29.2V25A
Weight:	2.05Kg
Dimension(LxWxH):	283x142x64mm
Continuous Out-put Power:	730W
IP Protection:	IP20
In-put Voltage:	AC220V~240V
In- Put Frequency:	47~63Hz
Out-put Voltage:	DC20V-DC29.2V
Out-put Current:	25A(±6%)
Working Temperature:	-10°C~+45°C
Saving Temperature:	20°℃~+60°C
Relative Temperature:	20-90%
Atmospheric Pressure:	70~106Kpa(No Condensation)
Cooling Way:	Intelligent Fan Control
Altitude:	≤3000m
Stable Current Charging Period:	24-27.6VDC
Stable Voltage Charging Period:	29.2VDC
Automatic Off Chargin:	Charging Voltage= 29.2V And Charging Current< 1A

Description

LFP 29.2V 25A RV Lithium Battery Intelligent Fan Control IP20 Protection

Ecolite LFP29.2V25A RV Lithium Battery

Specifications:

Basic Parameters	LFP 29.2V25A
Weight	2.05Kg
Dimension(LxWxH)	283x142x64mm
Continuous out-put power	730W
IP Protection	IP20
In-put Voltage	AC220V~240V
In-put Frequency	47~63Hz
Out-put Voltage	DC20V-DC29.2V
Out-put Current	25A(±6%)
Working Temperature	-10℃~+45℃
Saving Temperature	20℃~+60℃
Relative Temperature	20-90%
Atmospheric Pressure	70~106Kpa(No condensation)
Cooling Way	Intelligent fan control
Altitude	≤3000m
Stable Current Charging Period	24~27.6VDC
Stable Voltage Charging Period	29.2VDC
Automatic Off Chargin	Charging Voltage=29.2V and Charging Current< 1A
