LiFePO4 51.2V100Ah Lithium Ion Battery Pack For Solar Storage Energy System

Name: LiFePO4 51.2V100Ah Lithium Ion Battery Pack For Solar Storage Energy System
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: 48100
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Certification: UN38.3 MSDS CE RoHS

Model Number: 48100

Payment & Shipping Terms

Minimum Order Quantity: 500

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: L/C, T/T

Supply Ability: 4000 Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      LiFePO4 Lithium Ion Battery Pack, 51.2V 100Ah Lithium Ion Battery Pack


Rated Voltage:	51.2V	Nominal Capacity:	100Ah
Nominal Energy:	5120Wh	Communication:	RS485/RS232
Efficiency:	≥0.98	Internal Resistance:	≤30mΩ
Cycle Life:	>4000cycles	Discharge Temperature:	-20℃ To 60℃
Charge Temperature:	0℃ To 55℃	Cell Type-Chemistry:	LiFePO4 Cell

Rated Voltage:	51.2V
Nominal Capacity:	100Ah
Nominal Energy:	5120Wh
Communication:	RS485/RS232
Efficiency:	≥0.98
Internal Resistance:	≤30mΩ
Cycle Life:	>4000cycles
Discharge Temperature:	-20℃ To 60℃
Charge Temperature:	0℃ To 55℃
Cell Type-Chemistry:	LiFePO4 Cell

Description

LiFePO4 51.2V100Ah Lithium Ion Battery Pack For Solar Storage Energy System

LiFePO4 51.2V100Ah Bms Built in Lithium Ion Battery Pack for Solar Storage Energy System

FEATURES
Lithium lron Phosphate(LiFePO4):The Safest Lithium Technology.Integrated Battery Management System(BMS).Support multiple parallel connections. Multiple Communication Protocals:RS485,RS232.Unlimited Units Parallel Supported.House Made Smart BMS Technologies.

PERFORMANCE
Long Cycle Life >4000cycles@80%DOD High Density,High Discharge Current,High Tempera-ture Range.Low Weight,Free Maintenance.Fast Charging.Environment Friendly

Specifications

Electrical Parameters
Rated Voltage	51.2V
Nominal Capacity	100Ah
Nominal Energy	5120Wh
Internal Resistance	≤30mΩ
Efficiency	≥0.98
Cycle Life	>4000cycles @1C,80% DOD
Self Discharge	<5% per Month
Max.Modules in Series/Parallel	16S/1P

Mechanical Parameters
Dimension(WxDxH)	482.6x592x133mm
Dimension(WxDxH)	19x23.30x5.24
Weight	45.5kg
Trminal Type	FCC06B0
Battery Housing	Cold rolled steel sheet
Housing Protection	IP30
Cell Type-Chemistry	LiFePO4 Cell
Communication	RS485/RS232

Discharge Parameters
Continuous Discharge Current	100A
Pulse Discharge Current	150A (<0.5S)
Recommended Volt. Disconnect	40V
BMS Discharge Cut-off Voltage	40V
Reconnect Voltage	43.2V
Short Circuit Protection	300-800us

Charge Parameters
Charge Method	CC-CV
Charge Voltage	56.8-58.4V
Recommended Float Voltage	54~55.2V
Recommended Charge Current	50A
Maximum Charge Current	100A
BMS Charge Cut-off Voltage	59V

Temperature Parameters
Discharge Temperature	-20℃ to 60℃
Charge Temperature	0℃ to 55℃
Storage Temperature	-20℃ to 60℃
BMS High Temperature Cut-off	65℃

FAQ

Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
