Product Details
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Payment & Shipping Terms
Minimum Order Quantity: 100Units
Price: Inquiry
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 5000 units/month
Energy Storage System Code: |
21KWH |
Inverter: |
16A-230V |
Battery Nominal Voltage: |
51.2 VDC |
Battery Rated Capacity: |
410Ah |
Energy: |
21.5KWh |
Dimensions: |
850*570*760mm |
AC Input: |
Nominal 110VAC Range |
Outlet Socket: |
3×15A-230V |
Energy Storage System Code: |
21KWH |
Inverter: |
16A-230V |
Battery Nominal Voltage: |
51.2 VDC |
Battery Rated Capacity: |
410Ah |
Energy: |
21.5KWh |
Dimensions: |
850*570*760mm |
AC Input: |
Nominal 110VAC Range |
Outlet Socket: |
3×15A-230V |
Product Overview
This portable power box delivers quiet and clean electricity for a wide range of applications. Designed specifically for the Australian market with AC230V input and three 15A sockets, it provides a noise free, fuel free, and emission free power solution. Perfect for indoor enclosed spaces where traditional generators are not safe or allowed.
Battery Capacity Options
Choose between 15 kilowatt hours or 20 kilowatt hours of stored energy. This flexibility allows you to match the power box to your specific usage needs, from shorter events to extended off grid operations. The high capacity battery supports multiple full recharges of tools, appliances, or electronic equipment without needing grid power.
Charging Methods
Recharge the unit using standard mains power through an AC230V supply. For faster turnaround, connect an optional external 20KW charger to dramatically reduce downtime. This two way charging flexibility ensures you can adapt to available infrastructure, whether at a job site, workshop, or home.
Power Output Options
Select the output power level that suits your equipment: 5KW, 8KW, or 20KW. Lower settings preserve battery life for longer runtime, while 20KW output powers heavy duty machines and multiple high draw devices simultaneously. Each of the three 15A sockets provides reliable AC power for Australian standard plugs.
Quiet and Clean Operation
No internal combustion engine means zero noise, zero exhaust fumes, and no fuel storage risks. Use it inside offices, warehouses, hospitals, schools, or residential buildings without disturbing occupants or triggering air quality alarms. The silent operation also makes it ideal for film sets, exhibitions, and overnight events.
Safety First Design
Engineered with multiple protection systems including overload protection, short circuit protection, and temperature management. The battery chemistry and enclosure are built to rigorous safety standards, making this power box safe for unattended operation in sensitive environments.
Applications Across Industries
This portable power box serves many sectors. Construction sites use it for silent nighttime lighting, power tools, and site offices. Event organizers power sound systems, catering equipment, and display screens. Emergency response teams rely on it for backup power in disaster zones. Tradespeople bring it to remote job sites where grid access is limited. It also works as home backup power during blackouts, keeping refrigerators, internet routers, and medical devices running.
Extension and Usage Tips
Place the unit on a flat stable surface with adequate ventilation around the air intakes and exhaust. Connect devices one at a time and avoid exceeding the selected output power limit. For maximum battery lifespan, avoid fully depleting the unit before recharging. The AC230V mains charge is suitable for overnight top ups, while the external 20KW fast charger gets you back to full capacity in a fraction of the time for demanding daily cycles.
What’s Included
The portable power box comes with a standard AC230V charging cable suitable for Australian outlets. Three 15A sockets are built into the front panel. A digital display shows remaining battery percentage, current output power, and estimated runtime. The external 20KW fast charger is available as an optional accessory.
Environmental Benefits
Zero tailpipe emissions make this power box a greener alternative to petrol or diesel generators. It helps reduce carbon footprint on job sites and eliminates the risk of fuel spills. The battery is long lasting and recyclable at end of life.
Ideal for Australia
Rugged and reliable, this unit handles Australia’s diverse conditions from hot outback work sites to coastal humidity. The 15A sockets match standard Australian caravan, workshop, and trade outlets. With 230V input, it charges from any household or industrial socket without needing a step down transformer.
Warranty and Support
Backed by a standard manufacturer warranty. Technical support is available for troubleshooting, firmware updates, and service inquiries. For warranty claims, contact your local distributor with proof of purchase and unit serial number.
Final Summary
The Ecolite portable power box in 15KWh or 20KWh capacities brings silent, clean, and safe electricity wherever you need it. With three 15A sockets, selectable 5KW to 20KW output, and dual charging options (AC230V or external 20KW fast charger), this Australian market unit replaces noisy generators in indoor settings and remote locations. Ideal for trades, events, emergency backup, and off grid power needs.
| Basic parameters | |||||||||||
| Product code | 21kWh | ||||||||||
| Outlet socket | 3×15A-230V | ||||||||||
| Inlet | 15A-230V | ||||||||||
| nverter(Optional) | 5000VA,8000VA,10000VA | ||||||||||
| Inverter | 5000VA | 8000VA | 10000VA | ||||||||
| Rated inverter power (Continuous) | 5KVA | 8KVA | 10KVA | ||||||||
| Surge capacity(Peak) | 9KVA for 5 Secs | 15KVA for 5 Secs | 18KVA for 5 Secs | ||||||||
| Nominal output voltage | 230VAC | ||||||||||
| Frequency | 50Hz | ||||||||||
| AC voltage regulation(Battery Mode) | 230VAC±5% | ||||||||||
| Battery nominal voltage | 48VDC | ||||||||||
| Overload protection | 100ms @≥205%load,5s@≥150%load,10s@110%~150%load | ||||||||||
| AC input | Nominal 230VAC,Range 170-280VDC | ||||||||||
| Nominal input frequency | 50Hz | ||||||||||
| Lithium Batteries | 15KWh | 20KWh | |||||||||
| Battery nominal voltage | 51.2 VDC | ||||||||||
| Battery rated capacity | 314Ah | 410Ah | |||||||||
| Energy | 16kWh | 20kWh | |||||||||
| Battery cycle life(25℃,0.5C/0.5C,100%DOD) | >6000cycles,Remaining capacity>70% | ||||||||||
| Continuous discharge current | 300A | ||||||||||
| Pulse discharge current | 450A(<51S) | ||||||||||
| Discharge cut-off voltage | 40V | ||||||||||
| Reconnect voltage | 43.2V | ||||||||||
| Charge voltage | 56.8V~58.4V | ||||||||||
| Maximum charge current | 300A | ||||||||||
| Cell type-chemistry | LiFePO4 Cell | ||||||||||
| Operating temperature | Charge | 0℃~60℃ | |||||||||
| Discharge | -20℃~60℃ | ||||||||||
| Dimensions &Weight | |||||||||||
| Dimensions | 850×570×760mm (LxWxH) | ||||||||||
| Dry weight | Estimated 226kg | ||||||||||
| On Board Control Panel Equipped With | |||||||||||
| Battery monitor | sOC/Voltage/Curent /Monitoring | ||||||||||
| Battery ON/OFF switch | Fitted | ||||||||||
| Battery isolator | Fitted | ||||||||||
| RCBO protection | Fitted | ||||||||||
| High current charging interface | Fitted | ||||||||||
| Distribution Panel | |||||||||||
| 3×15A 1Ph 230V 3 Pin GPOs(RCBO Protected) | |||||||||||
| 1×15A 1Ph 230V3 Pin Inlet Trickle Charge(RCBO Protected) | |||||||||||
| 1×320A Rema | |||||||||||
