Highlight:
15000 Cycle LTO Pack
, 8C High Current Discharge
, 2 Hour Opportunity Charge
36V 80Ah LTO Battery Pack 15000 Cycles 8C Discharge Electric Floor Scrubber
Product Overview
This 36V 80Ah LTO battery pack is designed for electric floor scrubbers, sweepers and cleaning equipment, providing 15000 charge cycles and 8C discharge capability for demanding commercial cleaning operations. Cleaning machines run multiple shifts daily in shopping malls, airports, hospitals and factories - this battery is built to match that intensity for over a decade.
The sealed, maintenance-free design eliminates acid handling and watering tasks, while the high charge acceptance enables fast opportunity charging between shifts. Operators simply plug in during breaks and the battery tops up in minutes.
Core Selling Point: Multi-Shift Cleaning Power
- 15000 cycles: 12+ years of daily commercial cleaning
- 8C discharge: 640A peak for heavy scrubbing loads
- Opportunity charging: 30 minute top-up between shifts
- Zero maintenance: no water refilling, no acid handling
- Sealed design: safe for wet cleaning environments
- Consistent runtime: flat voltage curve maintains brush speed
Discharge Characteristics
| Discharge Rate | Capacity Retention | End Voltage | Max Duration |
|---|
| 0.5C (40A) | 100% | 34.2V | Continuous |
| 1C (80A) | 98% | 33.3V | Continuous |
| 4C (320A) | 95% | 31.5V | Continuous |
| 8C (640A) | 90% | 30.6V | 3 seconds (peak) |
Floor scrubbers draw heavy current when the brush deck engages wet surfaces. The LTO pack maintains voltage under these loads, keeping brush speed and suction power consistent for uniform cleaning results.
Charging Parameters
| Parameter | Standard Charging | Opportunity Charging |
|---|
| Charging Current | 1C (80A) | 4C (320A) |
| Charging Voltage | 40.8V (2.72V/cell) | 40.8V (2.72V/cell) |
| Charging Time (0-80%) | 45 minutes | 15 minutes |
| Charging Time (0-100%) | 1.5 hours | 25 minutes |
| Charge Efficiency | 97% | 95% |
| Recommended Charger | 36V 80A LTO charger | 36V 320A fast charger |
LTO vs Lead-Acid for Cleaning Equipment
| Parameter | LTO 36V 80Ah | Lead-Acid 36V |
|---|
| Cycle Life | 15000 cycles | 1200-1500 cycles |
| Charge Time | 15-25 minutes | 8-10 hours |
| Opportunity Charging | Supported | Not recommended |
| Maintenance | Zero | Weekly watering |
| Weight | Approx. 30kg | Approx. 70kg |
| Service Life | 12+ years | 2-3 years |
| Battery Change-Out | Not required | Required for multi-shift |
| Total Cost of Ownership | 40-60% lower | Baseline |
Technical Specifications
| Nominal Voltage | 36V |
| Nominal Capacity | 80Ah |
| Energy | 2.88 kWh |
| Cycle Life | 15000 cycles @ 80% DOD |
| Cell Chemistry | Lithium Titanate (Li4Ti5O12) |
| Cell Configuration | 12S (12 cells in series) |
| Max Discharge Rate | 8C (640A) pulse, 4C continuous |
| Max Charge Rate | 4C (320A) |
| Protection Rating | IP54 |
| Operating Temperature | -40 to 65 degrees C |
| Weight | Approx. 30kg |
| Communication | CAN bus, RS485 |
| Warranty | 5 years |
Smart BMS Protection
The BMS provides full protection and monitoring, with CAN bus output for equipment telemetry. Real-time SOC, SOH and fault data help fleet managers optimize cleaning schedules and maintenance.
| Protection Function | Threshold | Response |
|---|
| Overcharge Protection | 2.95V per cell | Disconnect charging |
| Over-discharge Protection | 1.5V per cell | Disconnect load |
| Overcurrent Protection | 8C (640A) | Disconnect within 3s |
| Short Circuit Protection | Immediate | Disconnect instantly |
| High Temperature Protection | 65 degrees C | Reduce current / cutoff |
| Cell Balancing | +/- 10mV | Active balancing |
Applications
- Electric floor scrubbers and sweepers
- Commercial cleaning equipment
- Airport and station cleaning machines
- Industrial warehouse sweepers
- Multi-shift cleaning operations
Quality Assurance & Certifications
- ISO 9001:2015 certified factory
- Cell level: UN38.3, UL1642, IEC62133 certified
- Pack level: CE, RoHS compliant
- 100% aging tested, 5-year warranty
Customization Options
- Capacity from 40Ah to 200Ah available
- Connector: Anderson, REMA, custom per drawing
- BMS communication protocol matched to equipment brand
- OEM / ODM service with private label
Frequently Asked Questions
Q1: Will this fit my floor scrubber?
A: The 36V 80Ah pack matches standard cleaning equipment platforms. Provide your battery compartment dimensions for fitment confirmation.
Q2: How long does it run per charge?
A: 80Ah supports 4-6 hours of continuous cleaning, extendable to full multi-shift operation with 15-minute opportunity charges.
Q3: Is it safe around water?
A: Yes. The sealed IP54 pack is protected against water splashes common in floor cleaning environments.
Q4: What is the payback period?
A: Most cleaning operators recover the investment in 12-18 months through eliminated battery change-outs, reduced energy cost and zero maintenance.
Contact us today for a quotation and technical consultation for your cleaning equipment fleet.
Dimension Options (Reference)
| Model | Length (mm) | Width (mm) | Height (mm) | Weight (kg) |
|---|
| LTO-36V80Ah-A | 460 | 320 | 240 | 30 |
| LTO-36V80Ah-B | 500 | 300 | 260 | 31 |
| LTO-36V80Ah-C (custom) | Per drawing | Per drawing | Per drawing | Varies |
Packaging & Shipping
| Item | Detail |
|---|
| Packaging | Export-grade wooden case, shock-proof foam insert |
| Transport Classification | UN3480, Class 9 dangerous goods |
| Documents | MSDS, UN38.3 test report, CO, Commercial Invoice |
| Shipping Methods | Sea freight, air freight (per regulation) |
| Lead Time | 15-25 days after deposit |
Why Choose LTO for Cleaning Equipment
Commercial cleaning equipment operates in wet, demanding environments - exactly where LTO excels. The sealed IP54 pack handles water splashes from scrubbing operations without concern. The 15000-cycle life eliminates the single largest operating cost of cleaning fleets: battery replacement. Multi-shift operators benefit from 15-minute opportunity charging, meaning one machine with one battery now does the work that previously required two machines or a battery change-out crew. For facility management companies running hundreds of scrubbers, the annual savings in batteries, labor and downtime are substantial.
Application Case Study
Case: Airport Terminal Cleaning Fleet
An international airport operates 40 floor scrubbers across its terminals with this 36V 80Ah LTO pack. Cleaning runs around the clock in 3 shifts. Previously, each scrubber needed two lead-acid batteries and nightly charging. With LTO opportunity charging, scrubbers top up for 15 minutes during shift changes. The airport eliminated 80 lead-acid batteries, freed up charging room space, and reduced annual battery-related costs by 45%.
