LiFePO4 12V 100Ah Portable Lithium Battery Pack For RV Caravan Boat Homes

Name: LiFePO4 12V 100Ah Portable Lithium Battery Pack For RV Caravan Boat Homes
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: LFP12100
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Certification: UN38.3 MSDS CE

Model Number: LFP12100

Payment & Shipping Terms

Minimum Order Quantity: 10Units

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: T/T, L/C

Supply Ability: 5000Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          12V Portable Lithium Battery Pack, Caravan Portable Lithium Battery Pack, RV LiFePO4 12V 100Ah Battery


Chemical Formula:	LiFePO4	Voltage:	12.8V
Rated Capacity:	100Ah	Energy:	1280Wh
Cycle Life:	>4000 Cycles @80% DOD, 1C/1D 25℃	Dimensions:	303x201x215mm
Weight:	10.1kg	Terminal Type:	M8
Max Charge Current:	100A	Max Discharge Current:	100A
Internal Resistance:	≤65mΩ	Operating Temperature:	-20°C To 60°C
Self Discharge Rate:	≤2% Per Month	Warranty:	3 Years
Certifications:	UN38.8，MSDS，CE，RoHS

Chemical Formula:	LiFePO4
Voltage:	12.8V
Rated Capacity:	100Ah
Energy:	1280Wh
Cycle Life:	>4000 Cycles @80% DOD, 1C/1D 25℃
Dimensions:	303x201x215mm
Weight:	10.1kg
Terminal Type:	M8
Max Charge Current:	100A
Max Discharge Current:	100A
Internal Resistance:	≤65mΩ
Operating Temperature:	-20°C To 60°C
Self Discharge Rate:	≤2% Per Month
Warranty:	3 Years
Certifications:	UN38.8，MSDS，CE，RoHS

Description

LiFePO4 12V 100Ah Portable Lithium Battery Pack For RV Caravan Boat Homes

LiFePO4 12V100Ah Lithium Battery Pack With BMS Portable Power For RV/Caravan/Boat/Homes/Solar/Outdoor

The Ecolite 12.8V100Ah battery pack uses Class A Prismatic LiFePO4 (lithium iron phosphate) cell 50Ah 100Ah 200Ah 300Ah cells with integrated smart battery management system (BMS).RS485 communication, optional Bluetooth, support series and parallel.Combine 2 for 24 Volts or 3 for 36 Volt or 4 for 48 Volt system.

This production can replace lead acid batttery,but don’t use LFP battery with VRLA battery or other brand battery, LFP is Safe,Long service life,High density,High discharge current, Temerature range,Light weight, free maintenance and many other advantages.

BATTERY DATA SHEET
ELECTRICAL PARAMETERS			MECHANICAL PARAMETERS
Nominal Voltage		12.8V	Dimension(L×W×H)	307x169x208mm
Rated Capacity		100Ah		12.09x 6.61x 8.19"
Energy		1280Wh	Weight	10.25kg
Resistance		≤25mΩ
Efficiency		≥98%	Terminal Type	M8
Cycle Life(1C,80%DOD,25℃)		>4000cycles	Battery Housing	ABS
Self Discharge		＜5% per Month	Housing Protection	IP65
Max. Cell in Series/ Parallel		4S/1P	Cell Type-Chemistry	LiFePO4 Cell
			Communication	Bluetooth

DISCHARGE PARAMETERS			CHARGE PARAMETERS
Continuous Discharge Current	100A		Charge Method	CC-CV
Pulse Discharge Current	160A (<10S)		Charge Voltage	14.2~14.6V
Recommended Volt. Disconnect	10V		Recommended Float Voltage	13.5~13.8V
			Recommended Charge Current	50A
BMS Discharge Cut-off Voltage	10V
			Maximum Charge Current	100A
Reconnect Voltage	12V		BMS Charge Cut-off Voltage	14.6V
Short Circuit Protection	300-800us

LiFePO4 12V 100Ah Portable Lithium Battery Pack For RV Caravan Boat Homes 0

Can Power For,

Rvs,Caravan,Golf Carts,Electric Vehicles,Boating &Sailboat,Home Energy Storage,Solar Storage, Emergency Power,Off Grid Energy Storage

12.8V Product Catalog.pdf
