Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS

Name: Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: 12V 200Ah
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite

Certification: UN38.3 MSDS CE

Model Number: 12V 200Ah

Payment & Shipping Terms

Minimum Order Quantity: 1000pcs

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 5-8 work days

Payment Terms: L/C, T/T

Supply Ability: 5000 units/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      LiFePO4 12V 200Ah Lithium Battery, Fast Charging 12V 200Ah Lithium Battery


Nominal Voltage:	12.8V	Rated Capacity:	200Ah
Energy:	2560Wh	Resistance:	≤65mΩ
Efficiency:	0.99	Cycle Life:	>2000cycles @1C,80% DOD
Self Discharge:	2% Per Month	Max. Modules In Series/Parallel:	4S/2P
Weight:	23kg(50.7bs)	Terminal Type:	M8
Battery Housing:	ABS, LG121	Housing Protection:	IP56
Cell Type-Chemistry:	LiFePO4 Cell	SOC Display(Optional):	/

Nominal Voltage:	12.8V
Rated Capacity:	200Ah
Energy:	2560Wh
Resistance:	≤65mΩ
Efficiency:	0.99
Cycle Life:	>2000cycles @1C,80% DOD
Self Discharge:	2% Per Month
Max. Modules In Series/Parallel:	4S/2P
Weight:	23kg(50.7bs)
Terminal Type:	M8
Battery Housing:	ABS, LG121
Housing Protection:	IP56
Cell Type-Chemistry:	LiFePO4 Cell
SOC Display(Optional):	/

Description

Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS

Fast Charging 12v 200Ah Lifepo4 Lithium Battery Pack With BMS

Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS 0

Electrical Parameters
Nominal Voltage	12.8V
Rated Capacity	200Ah
Energy	2560Wh
Resistance	≤65mΩ
Efficiency	0.99
Cycle Life	>2000cycles @1C,80% DOD
Self Discharge	2% per Month
Max. Modules in Series/Parallel	4S/2P

Mechanical Parameters
Dimension(L×W×H)	483x170x240mm
Dimension(L×W×H)	19 x 6.7x 9.4"
Weight	23kg(50.7bs)
Terminal Type	M8
Battery Housing	ABS, LG121
Housing Protection	IP56
Cell Type-Chemistry	LiFePO4 Cell
SOC Display(Optional)	/

Discharge Parameters
Continuous Discharge Current	120A
Pulse Discharge Current	300A (<30S)
Recommended Volt. Disconnect	10V
BMS Discharge Cut-off Voltage	8.8V
Reconnect Voltage	10.8V
Short Circuit Protection	300-800us

Charge Parameters
Charge Method	CC-CV
Charge Voltage	14.4~14.8V
Recommended Float Voltage	13.8V
Recommended Charge Current	30A
Maximum Charge Current	120A
BMS Charge Cut-off Voltage	15V

Temperature Parameters
Discharge Temperature	-20 to 60 ℃ (-4 to 140 ℉ )
Charge Temperature	0 to 60 ℃ (32 to 140 ℉ )
Storage Temperature	-40 to 70 ℃ (-40 to 158 ℉ )
BMS High Temperature Cut-off	78 ℃ (172.4 ℉ )

Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS 1

Fast Charging LiFePO4 12V 200Ah Lithium Battery Pack With BMS 4

NOTE: Do not Mix With Sealed Lead Acid Batteries When Recycling.
See User's Manual for Proper Operation.

Q :Do you provide free sample ?
A: Yes, a few pcs free sample can be provided, but freight will be charged

Q: what is the warranty?
A: one year

Q:What is your payment term ?
A: T/T,L/C

Q:do you accepte OEM order ?
A: Yes,you can print yourself logo, also we can provide the design of outlook for your special battery pack

Q :How many cells you can produce per month?
A: 1.8million

Q :What is the mode of transport?
A: usually by sea

Q:Which certificates do you have
A:We have un38.3,MSDS…etc.
