LiFePO4 Lithium Battery 48V20Ah For Household / Commercial Back Energy

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Payment & Shipping Terms

Minimum Order Quantity: 5000

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: L/C, T/T

Supply Ability: 5000Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Household LiFePO4 Lithium Battery, Commercial LiFePO4 Lithium Battery, 48V 20Ah LiFePO4 Lithium Battery


Nominal Voltage:	48V	Rated Capacity:	20Ah
Rated Energy:	960Wh	Resistance:	≤30mΩ
Effciency:	≥0.98	Cycle Life:	>2000cycles @1C,80% DOD
Self Discharge:	<5% Per Month	Max. Modules In Series/Parallel:	15S/3P
Weight:	13kg	Terminal Type:	M4
Pulse Discharge Current:	25A(＜10S)	Continuous Discharge Current:	20A
Cell Type-Chemistry:	LiFePO4 Cell	Communication:	RS485/RS232

Nominal Voltage:	48V
Rated Capacity:	20Ah
Rated Energy:	960Wh
Resistance:	≤30mΩ
Effciency:	≥0.98
Cycle Life:	>2000cycles @1C,80% DOD
Self Discharge:	<5% Per Month
Max. Modules In Series/Parallel:	15S/3P
Weight:	13kg
Terminal Type:	M4
Pulse Discharge Current:	25A(＜10S)
Continuous Discharge Current:	20A
Cell Type-Chemistry:	LiFePO4 Cell
Communication:	RS485/RS232

Description

LiFePO4 Lithium Battery 48V20Ah For Household / Commercial Back Energy

Ecolite LiFePO4 Lithium Battery 48V20Ah For Household/Commercial Back Energy
FEATURES:
Lithium lron Phosphate(LiFePO4)
The Safest Lithium Technology.
Integrated Battery Management System(BMS)
Support multiple parallel connections.

PERFORMANCE:
Long Cycle Life>2000cycles@80%DOD.
High Density,High Discharge Current,High Tempera-ture Range.
Low Weight,Free Maintenance.
Fast Charging.
Environment Friendly.

LiFePO4 Lithium Battery 48V20Ah For Household / Commercial Back Energy 0

SPECIFICATIONS:

Electrical Parameters		Mechanical Parameters
Nominal Voltage	48V	Dimension(WxDxH)	442x245x88mm
Rated Capacity	20Ah	Dimension(WxDxH)	17.4 x 9.64x3.464
Energy	960Wh	Weight	13kg
Resistance	≤30mΩ	Terminal Type	M4
Effciency	≥0.98	Battery Housing	SPCC
Cycle Life	>2000cycles @1C,80% DOD	Housing Protection	IP30
Self Discharge	<5% per Month	Cell Type-Chemistry	LiFePO4 Cell
Max. Modules in Series/Parallel	15S/3P	Communication	RS485/RS232

Discharge Parameters		Charge Parameters
Continuous Discharge Current	20A	Charge Method	CC-CV
Pulse Discharge Current	25A(<10S)	Charge Voltage	53.25-54.75V
Recommended Volt. Disconnect	37.5V	Recommended Float Voltage	50.6~51.75V
BMS Discharge Cut-off Voltage	37.5V	Recommended Charge Current	10A
Reconnect Voltage	40.5V	Maximum Charge Curent	20A
Short Circuit Protection	300-800us	BMS Charge Cut-off Voltage	54.75V

Temperature Parameters
Discharge Temperature		-20℃ to 60℃
Charge Temperature		0℃ to 55℃
Storage Temperature		-20℃ to 60℃
BMS High Temperature Cut-off		60℃
