Highlight:
24v 15Ah LiFePo4 Lithium Ion Battery
, Integrated BMS LiFePo4 Lithium Ion Battery
, Fast Charging LiFePo4 Lithium Ion Battery
BP2415-LFP Fast Charging AGV LiFePo4 Lithium Ion Battery 24v 15Ah Integrated BMS
Lithium Iron Battery For Warehouse Logistics AGV LFP 48V 50Ah
APPLICATION
Engineered to redefine material handling efficiency, our integrated lithium iron phosphate (LiFePO₄) battery system—paired with an advanced Battery Management System (BMS)—delivers exceptional performance, robust safety, and tangible cost optimization for Automated Guided Vehicle (AGV) fleets. This solution seamlessly combines cutting-edge energy storage technology with intelligent monitoring capabilities, ensuring prolonged operational uptime, minimized maintenance requirements, and enhanced fleet productivity. Designed for seamless integration into modern material handling ecosystems, our battery system sets a new standard for reliability and efficiency, empowering businesses to achieve sustainable operational excellence while reducing total cost of ownership.
PERFORMANCE
Long Cycle Life >2000cycles,
Remaining capacity>80%@25'C,0.5C/1C,100%DOD.
High Density,High Discharge Current,HighTemperature Range.
Low Weight,Free Maintenance.
Fast Charging,Support 2C fast charging.
Environment Friendly.
Three Views Of Product
Specification
| Electrical Parameters |
|
Nominal Voltage
|
25.6V |
|
Rated Capacity
|
15Ah |
| Energy |
384Wh |
| Resistance |
≤50mΩ |
| Efficiency |
≥0.98 |
| Cycle Life(25℃,0.5C/1C,100%DOD) |
＞2000cycles Remaining capacity＞80% |
| Self Discharge |
＜3% per Month |
| Cell in Series/Parallel |
8S/5P |
| Mechanical Parameters |
|
Dimension(L×W×H)
|
198*166*170mm |
| 7.80*6.54*6.69'' |
| Weight |
5kg |
| Terminal Type |
M8 |
| Battery Housing |
ABS |
| Housing protection |
IP65 |
| Cell Type-Chemistry |
LiFePO4 Cell |
| Communication |
Bluetooth |
| Discharge Parameters |
| Continuous Discharge Current |
30A |
| Pulse Discharge Current |
60A(<1S) |
| Recommended Volt. Disconnect |
20V |
| BMS Discharge Cut-off Voltage |
20V |
| Reconnect Voltage |
21.6V |
| Short Circuit Protection |
100-400us |
| Charge Parameters |
| Charge Method |
CC-CV |
| Charge Voltage |
28.4~29.2V |
| Recommended Float Voltage |
26.6~26.8V@100% |
| Recommended Charge Current |
7.5A |
| Maximum Charge Current |
15A |
| BMS Charge Cut-off Voltage |
29.6V |
| Temperature Parameters |
| Discharge Temperature |
-20℃ to 60℃ |
| Charge Temperature |
0℃ to 55℃ |
| Storage Temperature |
-20℃ to 35℃ |
| BMS High Temperature Cut-off |
65℃ |
