EcoLite LFP12.8V 70Ah: High-Power LiFePO4 Lithium Battery for Automotive Starting

500
MOQ
Inquiry
Price
EcoLite LFP12.8V 70Ah: High-Power LiFePO4 Lithium Battery for Automotive Starting
Features Gallery Product Description Request A Quote
Features
Specifications
Cell Type-Chemistry: LiFePO4 Cell
Nominal Voltage: 12.8V
Rated Capacity: 70Ah
Energy: 896Wh
Dimension(W×D×H): 279×175×189mm
Cell In Series/Parallel: 4S/3P
Cycle Life(0.5C,100%DOD,25℃): >8000cycles,70%SOH
Efficiency: ≥98%
Self Discharge: <2% Per Month
Basic Infomation
Place of Origin: China
Brand Name: Ecolite/OEM/ODM
Payment & Shipping Terms
Packaging Details: Carton Pallet Container
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 500000
Product Description

EcoLite LFP12.8V 70Ah: High-Power LiFePO4 Lithium Battery for Automotive Starting

Introducing the EcoLite LFP12.8V70Ah, a premium Lithium Iron Phosphate (LiFePO4) Lithium Battery engineered to deliver exceptional performance as an automotive starting battery. Built on advanced LiFePO4 technology, this battery combines robust power, longevity, and safety to redefine reliability for vehicle ignition systems.

Why Choose This LiFePO4 Lithium Battery for Your Vehicle?
Rapid Charging
: Fully charges in approximately 1 hour, ensuring minimal downtime and quick readiness for your next trip – a standout feature of this LiFePO4 Lithium Battery.
Lightweight Design: Weighs only half of traditional lead-acid batteries, reducing vehicle load without compromising performance – a key advantage of LiFePO4 Lithium Battery technology
Integrated BMS with Smart Protection: Equipped with a built-in Battery Management System (BMS) featuring self-balancing functionality, it safeguards against overcurrent, overtemperature, overvoltage, and undervoltage, ensuring operational safety – a critical feature of reliable LiFePO4 Lithium Batteries.
Emergency Readiness: Reserves 30% State of Charge (SOC) for emergency start-ups, providing peace of mind in unexpected situations.
Exceptional Longevity: Boasts an impressive cycle life of over 8000 cycles (at 0.5C, 100% Depth of Discharge (DOD), 25℃) with 70% State of Health (SOH) remaining, far outlasting conventional batteries – a hallmark of high-quality LiFePO4 Lithium Batteries.


Unmatched Starting Performance
This LiFePO4 Lithium Battery delivers extraordinary power for automotive starting:
High Current Capability: Offers a continuous discharge current of 200A and a pulse discharge current of 1000A (<3S), paired with a 1000 CCA (Cold Cranking Amps) rating (tested by DY-2015), ensuring reliable ignition even in extreme conditions.
Wide Temperature Adaptability: Operates seamlessly in discharge temperatures from -40℃ to 85℃ and charge temperatures from -30℃ to 85℃, making it suitable for harsh climates – a testament to the durability of LiFePO4 Lithium Battery chemistry.



Technical Specifications of This LiFePO4 Lithium Battery:
Electrical: Nominal Voltage 12.8V | Rated Capacity 70Ah | Energy 896Wh | Self Discharge <5% per Month.
Mechanical: Compact dimensions (279x175x189mm) | Lightweight (10kg) | IP65 housing protection for dust and water resistance.
Safety & Compliance: CE certified, with BMS high-temperature cut-off at 85℃, ensuring safe operation.


For drivers and fleet managers seeking a powerful, long-lasting, and safe automotive starting solution, the EcoLite LFP12.8V60Ah LiFePO4 Lithium Battery is the ultimate choice. Experience the superior performance of LiFePO4 technology for your vehicle.


Mechanical Parameters
Dimension(W×D×H) 279×175×189mm
Dimension(W×D×H) 10.98×6.89×7.74’’
Weight 10kg
Terminal Type Post
Battery Housing ABS
Housing Protection IP65
Cell Type-Chemistry LiFePO4 Cell
Communication /



Electrical Parameters
Rated Voltage 12.8V
Rated Capacity 70Ah
Nominal Energy 896Wh
Resistance ≤7mΩ
Efficiency ≥98%
Cycle Life(0.5C,80%DOD,25℃) >8000cycles,70%SOH
Self Discharge <5% per Month
Cell in Series/Parallel 4S/3P



Discharge Parameters
Continuous Discharge Current 200A
Pulse Discharge Current 1000A(≤1S)
CCA(Tested by DY-2015) 1000CCA
BMS Discharge Cut-off Voltage 8.8V
Reconnect Voltage 10V



Charge Parameters
Charge Method CC-CV
Charge Voltage 14.4~14.6V
Recommended Float Voltage 13.5~13.8V
Recommended Charge Current 70A
Maximum Charge Current 200A
BMS Charge Cut-off Voltage 15.6V



Temperature Parameters
Charge Temperature -40 to 85 ℃(-40℃,0.2C)
Discharge Temperature -30  to 85 ℃(-30℃,0.2C)
Storage Temperature -20℃ to 25 ℃(1 year)
BMS High Temperature Cut-off 85℃

EcoLite LFP12.8V 70Ah: High-Power LiFePO4 Lithium Battery for Automotive Starting 0

Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
