Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack

Name: Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack
Brand: HEFEI ECOLITE ENERGY CO., LTD.
SKU: LTO24-30
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Ecolite/OEM/ODM

Model Number: LTO24-30

Payment & Shipping Terms

Minimum Order Quantity: 50

Price: Inquiry

Packaging Details: Carton Pallet Container

Delivery Time: 1-2 months

Payment Terms: L/C, T/T

Supply Ability: 5000 Units per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Lithium Titanate LTO Battery Pack, 24V 31.2Ah LTO Battery Pack


Rated Voltage:	24V	Nominal Capacity:	31.2Ah
Rated Energy:	748.8Wh	Internal Resistance:	≤12mΩ
Maximum Charge Current:	60A	Self Discharge:	<2% Per Month
Size（W×D×H）:	260×168×209mm	Operating Temperature:	Charging:-40℃ To 60℃ Discharge: -40℃ To 60℃

Rated Voltage:	24V
Nominal Capacity:	31.2Ah
Rated Energy:	748.8Wh
Internal Resistance:	≤12mΩ
Maximum Charge Current:	60A
Self Discharge:	<2% Per Month
Size（W×D×H）:	260×168×209mm
Operating Temperature:	Charging:-40℃ To 60℃ Discharge: -40℃ To 60℃

Description

Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack

Features

Lithium Titanate(LTO):the Safest Lithium Technology.Integrated Battery Management System(BMS).battery protection function:Overcurrent, overvoltage, overcharging, overdischarge, short circuit, Effectively protect the battery from damage and extendthe battery life Stable and effectiveprotection in the eventof extreme battery problems.

Performance

Long Cycle Life＞10000cycles@80％DOD.

High Density,High Discharge Current.

No Fire, Less heat generation when short-circuited,Fast heat dissipation and Longer life.

Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack 0

Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack 1

Electrical Parameters		Mechanical Parameters
Nominal Voltage	24V	Dimension(WxDxH)	260x168x209mm
Rated Capacity	31.2Ah	Dimension(WxDxH)	10.24 x6.61x8.23
Nominal Energy	748.8Wh	Product Weight	11kg
Internal Resistance	≤12mΩ	Terminal Type	M8
Efficiency	≥0.99	Battery Housing	ABS
Cycle Life	>10000cycles @1C,80% DOD	Housing Protection	IP65
Self Discharge	<2% per Month	Cell Type-Chemistry	LTO Cell
Cell in Series/Parallel	10S/24P	Communication	/

Discharge Parameters		Charge Parameters
Continuous Discharge Current	60A	Charge Method	CC-CV
Pulse Discharge Current	100A (<3S)	Charge Voltage	27.5-28.5V
Recommended Volt. Disconnect	15V	Recommended Float Voltage	27.5V
BMS Discharge Cut-off Voltage	17V	Recommended Charge Current	15A
Reconnect Voltage	20V	Maximum Charge Current	60A
Short Circuit Protection	200-500us	BMS Charge Cut-off Voltage	28.5V

Temperature Parameters
Discharge Temperature		-40℃ to 60℃
Charge Temperature		-40℃ to 60℃
Storage Temperature Range		-10℃ to 35℃
BMS High Temperature Cut-off		75℃

Longlife Safety Fast Charging Lithium Ion LTO 24V 31.2Ah Lithium Titanate Battery Pack 2

Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
